Common Interface Click on pic for inside view	Specifications	Testing Results Click here for receiver compatibility list	Downloads
Circuit Diagram	( Euro ) Irdeto II based on the Philips 8051XA microcontroller ( P/N : 901205 ) Ver. 01.05 , softcell Ver. 2.09 , compiled 22/Sep/2000 , flashable a single time ( P/N : 901275 ) Demux Ver. 01.06 , softcell Ver. 2.09 , compiled 12/Oct/2000 , non-flashable DVB number: 00 1608 ( P/N : 904063 ) Demux Ver. ??.?? , softcell Ver. ?.?? , compiled ??/???/???? , non-flashable DVB number: 00 2297 Common Interface Irdeto II Only CAM Software exists however to switch it to Aston Ver. 1.05 and Viaccess RED (can't be programmed via laptop) PIN : 6962 ( DEFAULT ) Parental Control PIN ( NOVA DEFAULT ) = 1234	- Original Card NOVA..... Test O.K. - Original Card EURO1080..... Test O.K. - Original Card MCT..... Test O.K. - Original Card REDLIGHT..... Test O.K. - Fun Card..... ( 6 in 1 ) Test O.K. ( in some receivers with special firmware ) - Gold Card..... Test O.K. - GammaCard..... Test O.K. -> Emm : Disabled -> Ecm : Disabled -> Auto Update : OFF	Upgrade Pack Ver. 1.05 Ver. 1.06 Ver. 1.07 Ver. 1.10 How to do
Back Side Ver. 4.78 Back Side Ver. 4.84 Circuit Diagram	( Euro ) Viaccess (Red) ( P/N : 901273 ) V 477 Rev. 1.0 Ver. 1.0 ( P/N : 901273 ) V 478 Rev. 1.1 Ver. 1.0 ( P/N : 902513 ) V 481 Rev. 1.0 Ver. 1.0 ( P/N : 902532 ) V 481 Rev. 1.0 SCA: 001 ( P/N : 903182 ) Viasat Sweden on Nokia 9321S ( P/N : 903457 ) V 483 ( P/N : ) V 484 Common Interface Viaccess I & II CAM Software exists however to switch it to Aston Ver. 1.05 and Irdeto II (can't be programmed via laptop) Ver. 4.77, Ver. 4.78, Ver. 4.81 or Ver. 4.83 cannot be upgraded to Ver. 1.10 and Ver. 1.20 due to difference in Chips. Any attempt to do so will resolve in destruction of your Module "W" (Ver. 2.4 ) = Viaccess II Cards Parental Control PIN ( ALPHA DIGITAL DEFAULT ) = 1234	- Original Card "W" (Ver. 2.4) TPS..... Test O.K. - Original Card "W" (Ver. 2.4) ALPHA DIGITAL..... Test O.K. - Original Card MCT..... Test O.K. - Original Card REDLIGHT..... Test O.K. - Original Card SEX ON TV..... Test O.K. - Original Card SEX VIEW..... Test O.K. - Original Card SEX VIEW HQ..... Test O.K. - Fun Card..... Test O.K. - Gold Card..... Test O.K. (1.0 Ver. 477 Application Ver. 1.05.001): -> * (1.0 Ver. 478 Application Ver. 1.05.001): -> * (1.0 Ver. 481 Application Ver. 1.05.001): -> * - Original Card "W" (Ver. 2.4) ALPHA DIGITAL..... Test Failed (1.0 Ver. 483 Application Ver. 1.05.001): -> * (1.0 Ver. 484 Application Ver. 1.06.001): -> * (1.0 Ver. 484 Application Ver. 1.07.004): -> *	Upgrade via Sat 12.??? GHz H SR 27500 FEC 3/4 on HOT BIRD Upgrade Pack Ver. 477 Ver. 478 Ver. 481 Ver. 483 Ver. 484 How to do
Back Side Ver. 1.03 Back Side Inside Ver. 1.05 Back Side Ver. 1.05 Circuit Diagram Back Side Inside Ver. 1.07	( Euro ) Astoncrypt (Seca / Mediaguard) based on the Philips 8051XA embedded CPU ( P/N : 900836 ) Ver.1.00 , `flashable` ( P/N : 900836 ) Ver.1.03 , `flashable` ( P/N : 901274 ) Ver.1.04 , non-`flashable` ( P/N : ) Ver.1.04r1 ( P/N : 901274 ) Ver.1.05 Rev. 1.1 , non-`flashable` ( P/N : ) Ver.1.07 Common Interface Seca I & II CAM Software exists however to switch Ver. 1.03 to Cryptoworks and we have heard of this being converted to Nagravision too (but Nagravision has a IRD & BoxKey in protected part of flash and can't be programmed via laptop) Software exists however to switch Ver. 1.05 to Conax Ver. 4.0e, Irdeto II and Viaccess RED (can't be programmed via laptop) Ver. 1.03 also seems to work best for ITV Digital but it should be stressed that these CAMs aren't designed for this (Ver. 6.0 ) = Seca Cards (Ver. 7.0 ) = Seca II Cards (Ver. 7.0 ) = Seca II Cards	- Original Card DIGITAL+..... Test O.K. - Original Card TPS..... Test O.K. - Original Card BIS..... Test O.K. - Original Card `CYFRA +`..... Test O.K. - Original Card `POLSAT`..... Test O.K. - Titanium Card..... Test O.K. Titanium II Card..... Test O.K. - Fun Card..... Test O.K. - Gold Card..... Test O.K. -> Lock consultation : OFF -> Lock moral level : OFF -> Lock PPV P : OFF -> Lock PPV T : OFF	Upgrade via Sat 12.092 GHz H SR 27500 FEC 3/4 on HOT BIRD 2 Application Ver. 1.05 or Newer SCT Channel Upgrade Pack Ver. 1.00 (Crypto Hardware) Ver. 1.03 (Crypto Hardware) Ver. 1.04 Ver. 1.05 Ver. 1.07 Aston <-> Crypto How to do Aston -> Irdeto Freecam (only possible with external eeprom flash)
Back Side Back Side Circuit Diagram	( Euro ) Conax ( P/N : 900165 ) ( P/N : 901647 ) Rev. 1.0 Common Interface Conax CAM Also known as "CAS 3"	- Original Card DigitAlb..... Test O.K. - Titanium Card..... Test O.K. - Titanium II Card..... Test O.K. - Fun Card..... Test O.K. - Gold Card..... Test O.K. - Pentacard VR1..... Test O.K. - Pentacard VR3..... Test O.K. - M2 Plus Card..... Test O.K.	Upgrade Pack Ver. 1.08 Ver. 2.01 Ver. 3.03 (Viaccess Black Hardware) Ver. 4.00 How to do Conax -> Irdeto Freecam (only possible with external eeprom flash)
	( Euro ) Irdeto Conax Common Interface Irdeti II & Conax CAM	- Original Card NOVA..... Test O.K. - Original Card EURO1080..... Test O.K. - Original Card MCT..... Test O.K. - Original Card REDLIGHT..... Test O.K. - GammaCard..... Test O.K. - Original Card DigitAlb..... Test O.K. - M2 Plus Card..... Test O.K.
Back Side Circuit Diagram	( Euro ) CryptoWorks ( P/N : 901632 ) Rev. 1.2 Common Interface Cryptoworks CAM Software exists however to switch it to Aston Ver. 1.05 and we have heard of this being converted to Viaccess BLACK too (can't be programmed via laptop)	(Ver. 1.12.000): - Original Card CzechLink.....Test O.K. - Original Card UPC Direct / Wizja Tv.... Test Failed - Original Card `Digiturk`..... Test O.K. - Original Card MTV Networks..... Test O.K. (Ver. 1.14.000): - Original Card CzechLink.....Test O.K. - Original Card UPC Direct / Wizja Tv.... Test Failed - Original Card `Digiturk`..... Test O.K. - Original Card MTV Networks..... Test O.K. (Ver. 1.15.006): - Original Card CzechLink.....Test O.K. - Original Card UPC Direct / Wizja Tv.... Test Failed - Original Card `Digiturk`..... Test O.K. - Original Card MTV Networks..... Test O.K. (Ver. 1.15.015): - Original Card CzechLink.....Test O.K. - Original Card UPC Direct / Wizja Tv....Test O.K. - Original Card `Digiturk`..... Test O.K. - Original Card MTV Networks..... Test O.K.	Upgrade Pack Ver. 1.12 Ver. 1.14 Ver. 1.15.15 Crypto <-> Aston How to do
	Nagravision GEMPLUS Technology ( P/N : ) ( BoxKey: ???????????? ) Common Interface Nagravision CAM	- Original Card TV Cabo.....Test O.K. - Original Card Via Digital.....Test O.K. - Gold Card..... Test O.K.	Upgrade Pack Ver. 1.1 Ver. 1.2 (Aston Hardware) Ver. 1.36 How to do Find the BoxKey Vacuna How to do
The first legal Multicrypt module	( Euro ) AlphaCrypt ( P/N : 901275 ) DVB number: 001608 ( P/N : 901650 ) Rev. 1.0 ( P/N : 901650 ) Rev. 1.1 DVB number: 002275 Common Interface Emulates Irdeto I (license from Irdeto) Emulates Irdeto II (license from Irdeto) Emulates BetaCrypt Emulates CryptoWorks (license from Philips) (only on firmware version 2.1 & 2.3) Emulates Conax (license from Telenor) (will be supported soon) Press Release Parental Control PIN Ver. 1.10 = 0000 Ver. 2.00 - 3.0? = 1973 Parental Control PIN ( NOVA DEFAULT ) = 1234 Admitted error for Ver. 2.0	- Original Card Premiere..... Test O.K. - Original Card NOVA..... Test O.K. - Original Card Stream..... Test O.K. - Original Card ORF..... Test O.K. - Gold Card..... Test O.K. (Ver. 1.0 Compiled at 15.5.2001): -> * (Ver. 1.0 WT Compiled at 19.5.2001): -> * (Ver. 1.10 Compiled at 28.02.2002): -> * (Ver. 2.00 Compiled at 07.05.2003): -> * (Ver. 2.10 Compiled at 03.07.2003): -> * - Original Card MTV Networks..... ( Cryptoworks ) Test O.K. Bug on Parental Control PIN (can not been chenged) new firmware will be realesed in about 4 weeks time. (Ver. 2.20 Compiled at ??.??.2003) * - Original Card MTV Networks..... Test Failed (Ver. 2.3 Compiled at ??.??.2003) * - Original Card MTV Networks..... ( Cryptoworks ) Test O.K. (Ver. 3.03 Compiled at ??.??.2004) * - Original Card MSAT Telenor..... Test ???? - Titanium Card..... ( Conax ) Test ????	Upgrade via Sat 12.692 GHz H SR 22000 FEC 5/6 PID 00546 on ASTRA 1 Firmware Ver. 1.10 is necessary ORF1 / ORF2 / TW1 Upgrade Pack Ver. 1.0 Ver. 1.0 WT Ver. 1.0 for Nokia 9600 Ver. 1.10 Ver. 1.10 for Nokia 9600 Ver. 2.00 Ver. 2.1 Ver. 2.2 Ver. 2.3 Ver. 3.0? (will be published soon) How to do
This CAM offered by Mascom GmbH Germany	( Euro ) AlphaCrypt Light ( P/N : 904410 ) Rev. 2.0 DVB number: 2275 Common Interface
This CAM offered by Mascom GmbH Germany	( Euro ) AlphaCrypt ( P/N : 904315 ) DVB number: 2297 Common Interface
	NDS Module ( P/N : ) Common Interface VideoGuard Only CAM For Satellite, Cable and terrestrial STB	- Original Card Sky Digital..... Test O.K. - Original Card Sky Italia..... Test O.K.
sorter than other ci Back Side Original Card	Top Up TV Smartcard Adaptor ( P/N : ) Non Standard Common Interface Seca I CAM Designed only for Sony TV DX30	- Original Card ON Digital.....Test O.K. (on official receiver or on a compatible terrestrial one) - Gold Card..... Test Failed - Nokia 9850 DVB-T..... Test Failed
This CAM offered by Mascom GmbH Germany Back Side Officially licensed by irdeto access	InXworld ( P/N : 904245 ) Rev. 1.0 DVB number: 002297 Common Interface	- Original Card NOVA..... Test O.K.
	Ultimate Cam ( P/N : 904074 ) Rev. 1.0 Common Interface Emulates Irdeto I Emulates Irdeto II Emulates Conax Flash 2 x 29SF040 ( more than one time flashable )	- Original Card NOVA..... Test O.K. All channels with 4 months subscription to start when you want
	easy.tv CAM ( P/N : ) Common Interface
Back Side Gold Wafer Repair File FunCard 7 Repair File	Dragon Module ( P/N : 8105/2003 ) Rev. 2.05 ( P/N : 8105/2003 ) Rev. 2.06 ( P/N : 8105/2003 ) Rev. 3.00 ( P/N : 8105/2003 ) Rev. 3.01 ( P/N : 8105/2003 ) Rev. 3.02 ( P/N : 8105/2003 ) Rev. 3.03 Common Interface Based on pred@tor To program this device you will need a separate loader card Gold Wafer or FunCard 7 Do not AUTO-DETECT the dragon loader card using any programmer. If you do this you run a real risk of damaging the loader card just set the programmer to PHOENIX mode at 6.0mhz and then use the dragon loader software do not do anything else than the above when dealing with this particular card.	Supported in the latest version : Irdeto Irdeto II BetaCrypt VIACCESS VIACCESS II TPSCrypt Seca Seca II Nagravision Conax Cryptoworks Dreamcrypt (for XDreamTV Card) http://www.dragonmodule.com/ - Original Card SkyDigital..... Test O.K. ( just add S/N of the STB on the cam ) - Original Card NOVA..... Test O.K.	Upgrade Pack Predator Ver. 0.1 Ver. 0.4 Ver. 0.5 Ver. 1.0 Ver. 1.1 Ver. 1.3 Ver. 1.4 Ver. 1.6 Ver. 2.01 Ver. 2.02 Ver. 2.03 Ver. 2.11 Ver. 2.12 Ver. 2.14 Ver. 2.15 Ver. 2.16 Ver. 2.17 Ver. 2.18 Ver. 2.19 Ver. 2.20 Ver. 2.22 Ver. 2.23 Ver. 2.25 Ver. 2.29 Ver. 2.31 Ver. 2.32 Ver. 2.33 Ver. 2.34a Ver. 3.01 Ver. 3.02 Ver. 3.03d How to do Nokia 9800S & 9902S CI Interface Modification
Back Side Gold Wafer Repair File FunCard 7 Repair File	Dragon II Module ( P/N : 8105/2003 ) Rev. 4.1 Common Interface Based on pred@tor To program this device you will need a separate loader card Gold Wafer or FunCard 7 Do not AUTO-DETECT the dragon loader card using any programmer. If you do this you run a real risk of damaging the loader card just set the programmer to PHOENIX mode at 6.0mhz and then use the dragon loader software do not do anything else than the above when dealing with this particular card.	Supported in the latest version : Irdeto Irdeto II BetaCrypt VIACCESS VIACCESS II TPSCrypt Seca Seca II Nagravision Conax Cryptoworks Dreamcrypt (for XDreamTV Card) - Original Card SkyDigital..... Test O.K. ( just add S/N of the STB on the cam ) - Original Card NOVA..... Test O.K.	FireCrypt How to do Nokia 9800S & 9902S CI Interface Modification
This CAM offered by MAXKING INTERFACES LTD Back Side	MATRIX RELOADED ( P/N : ) Common Interface Based on SIDSA Also known as UCAS v2.0 Xilinx XC9536XL CPLD Version 3 Flash: TOSHIBA TC58FVT160AFT Flash: AM29LV160BB Flash: ST M29W160DB Flash: MBM29LV800B(A) Xilinx XC9536XL CPLD Version 4 Flash: HYNIX HY29LV160	Supported in the latest version : Irdeto Irdeto II BetaCrypt VIACCESS VIACCESS II TPSCrypt Seca Seca II Nagravision (with selectable BoxKey) Conax	Windows Drivers TOOLS Ver. 1.130 MRCrypt Ver. 1.90 MRFM Ver. 1 RC5 sep Ver. 1.1 MultiEmu Ver. 0.35 Ver. 0.36 Ver. 0.38 Ver. 0.40 Ver. 0.42 Ver. 0.44 MultiEmuEdit Ver. 1.06 How to do MuTZNuTZ Ver. 1.6 Nokia 9800S & 9902S CI Interface Modification
	MATRIX REBORN ( P/N : ) Common Interface Also known as UCAS v3.1	Supported in the latest version : Irdeto Irdeto II BetaCrypt VIACCESS VIACCESS II TPSCrypt Seca Seca II Nagravision (with selectable BoxKey) Conax
Back Side	MATRIX REVOLUTION ( P/N : ) Common Interface Also known as UCAS v3.1	Supported in the latest version : Irdeto Irdeto II BetaCrypt VIACCESS VIACCESS II TPSCrypt Seca Seca II Nagravision (with selectable BoxKey) Conax	Ver. 2.00 Ver. 2.01 Ver. 2.02 Ver. 2.03 Ver. 2.04 Ver. 2.05 Ver. 2.06 Ver. 2.07 Ver. 2.09 Ver. 2.11 Ver. 2.12 Ver. 2.13 Ver. 2.14 Ver. 2.17 Ver. 2.18 MRVCrypt Ver. 1.12 Nokia 9800S & 9902S CI Interface Modification
Back Side	XCAM / ULTRACAM ( P/N : 030723 ) Ver. 1.0 Common Interface	Supported in the latest version : Irdeto Irdeto II BetaCrypt VIACCESS VIACCESS II TPSCrypt Seca Seca II Nagravision (with selectable BoxKey) Conax	Upgrade Pack Key2Hex Ver. 1.01 Ver. 1.02 Ver. 1.03t Ver. 1.04 Ver. 1.05 Ver. 1.06 Ver. 1.062 Ver. 1.064 Ver. 1.070 Ver. 1.071 Ver. 1.072 Ver. 1.073 Ver. 1.075 Ver. 1.076 Ver. 1.077 Ver. 1.078 Ver. 1.080 Ver. 1.082t Ver. 1.083 Ver. 1.084 Ver. 1.085 Ver. 1.086 Ver. 1.087 Ver. 1.088 Ver. 1.091 Ver. 1.092 Ver. 1.094 Ver. 1.095 Ver. 1.10 Ver. 1.11 How to do Nokia 9800S & 9902S CI Interface Modification
	XCAM Premium ( P/N : ) Common Interface	Supported in the latest version : Irdeto Irdeto II BetaCrypt VIACCESS VIACCESS II TPSCrypt Seca Seca II Nagravision (with selectable BoxKey) Conax	Upgrade Pack Key2Hex Ver. 1.02 Use XCAM / ULTRACAM Firmware How to do Nokia 9800S & 9902S CI Interface Modification
	Reality Cam ( P/N : ) Common Interface	Supported in the latest version : Irdeto Irdeto II VIACCESS VIACCESS II TPSCrypt Seca Seca II Conax Cryptoworks	Ver. 1.0.2 Ver. 1.0.3 Ver. 1.0.4 Ver. 1.0.5 Ver. 1.0.6 Ver. 1.0.9 Ver. 1.0.11 Ver. 1.0.12 Ver. 1.0.14 Ver. 1.0.15 Nokia 9800S & 9902S CI Interface Modification
	SUPER JOKER ( P/N : ) Common Interface		Nokia 9800S & 9902S CI Interface Modification
Official Back Side Unofficial Back Side Datasheets	Magic Module ( P/N : 8103/2002 ) Rev. 1.01 ( P/N : 8103/2002 ) Rev. 1.02 ( P/N : 8104/2002 ) Rev. 1.03 (Comes from Taiwan, but same as the 1.02 / Official modules have a '3d-label') ( P/N : 8105/2002 ) Rev. 1.04 (Official modules have a '3d-label') ( P/N : 8106/2002 ) Rev. 1.05 (Official modules have a '3d-label') Rev. 1.01 vs. Rev. 1.02 & Rev. 1.02 vs. Rev. 1.03 & Rev. 1.03 vs. Rev. 1.04 Processor Module with smartcard reader. On this development platform you can develop your own smartcard applications. This module contains a fast ARM processor, a big RAM memory and a flash module. Together with the programmer you can load your own applications into this module, for example applications to: Common Interface Encrypt data traffic, using smartcards, in laptops (mobile business) A laptop smartcard reader/writer Access control for laptops Development platform for your own DVB encoding systems If you want to use it on a NOKIA 9600 or 9600S needs to be upgraded with Dr. Overflow's DVB 2.00.0 BETA08 Magic or Dr. Overflow's DVB 1.82.00 NoOnem13h Based on SIDSA Xilinx XC9536XL CPLD Version 3 Flash: TOSHIBA TC58FVT160AFT Flash: AM29LV160BB Flash: ST M29W160DB Flash: MBM29LV800B(A) <- To program this device you will need a separate programmer and a RS-232 cable not a laptop with a PCMCIA port The programmer should be connected to the serial port ( COM1 ή COM2 ), and is placed in the module, as a smartcard Connection using 9 pin serial connector (not a null modem cable) Free programmable PCMCIA-Module with integral card-reader as ISO-Norm, 68 pin PCMCIA-connector. 5V PC-Card with 3.3V chiptechnology internal (very low thermal producing) ARM7 Prozessor 30 MHz 256k RAM, 2MB flash	Supported in the latest version : Irdeto Irdeto II BetaCrypt VIACCESS VIACCESS II TPSCrypt Seca Seca II Nagravision (with selectable BoxKey) Conax Dreamcrypt (for XDreamTV) New in this version - No checks, no killers, no expiration, no nothing, just a safe version for all to enjoy. - Added support for DreamCrypt cards - Fix for new Premiere S2 cards. - Fix for non-standard MECMs on Nagra providers 40/41 and 48/49. It works with all types of cards (no matter who the manufacturer) -> Goalkeeper : OFF -> Suppress No-Access Message : OFF When you have a Ucas module or the Extreme receiver. Don't place the PentaCrypt Ver. 1.11 on it. It will crash the flash. Fake MM Versions MultiFirmware 3.11 = Penta 1.05 Penta 2.00 = Penta 1.00 Penta 1.10 all ci = Penta 1.10 BETA	Windows Drivers Loader for COM1 & COM2 Loader for COM3 & COM4 Linux Drivers Linux Upgrade Pack SDK Ver. 1.0 arm-elf-cygw core-library PentaCrypt Ver. 1.09 Ver. 1.20 Use MRV Firmware How to do Magic to UCAS Ver. 2.0 How to do Find the BoxKey Nokia 9800S & 9902S CI Interface Modification
Original Matrix is sorter than other ci	MATRIX ( P/N : ) Common Interface Based on SIDSA Clone of the Magic Module Rev. 1.02	Same as MM	Use MRV Firmware
	Global Cam ( P/N : ) Common Interface Based on SIDSA Clone of the Magic Module Rev. 1.02	Same as MM	GlobeCrypt or Use MRV Firmware
	BETA ( P/N : 8613/2002 ) Rev. 1.02 Common Interface Based on SIDSA Clone of the Magic Module Rev. 1.02	Same as MM	Use MRV Firmware
	Universal Penta ( P/N : ) Common Interface Based on SIDSA
